Vertical 3-axis CNC lathe specially developed for diamond grinding and external turning of small parts.

The advantages of the technology developed and implemented by Neotec SA are

• Stability in the repeatability of machining operations linked to a flawless positioning accuracy.
• Elimination of all vibrations thanks to a high quality reinforced spindle, an optimised spindle motor drive system and a robust chassis.
• Safety features that meet all standards for safe working.
• The integration of 3 machining axes allows simultaneous or sequential action of three complex operations for notching, chamfering or shaping complex and delicate parts.
• Cutting tool replacement and adjustment is facilitated by simple and efficient CNC controls. In addition, the double extension of the safety gates allows easy adjustment of the chisels.
• Adjustable automatic part ejection after each machining cycle.
• The Fanuc CNC control and EIP 700 offer simplicity of operation and customised adjustment possibilities for our customers. A simple PC application allows all completed parts to be programmed and saved, thus further reducing set-up times.
• Minimal maintenance costs due to central lubrication, perfect chip protection of the slides and high-quality machine components.

A spray lubrication system and compressed air cleaning of the fixtures can also be installed.
